Generator set	Type	Open	Open with ATS	Silent	Silent with ATS
	Genset Model	DK30640	DK30640A	DK30640S	DK30640SA
	Prime Power Rating	80KVA/64KW
	Standby Power Rating	88KVA/70.4KW
	Size(mm)	2000*850*1200		2600*1100*1600
	Weight(KG)	1100		1850
	Internal protection	IP22
	Rate current(A)	115
	Specific Fuel Consumption(g/kW·h)@100% Load	≤192
	Noise at 7 meters away(dB)	N/A		75db
Engine	Model	Deutz BF4M2012C G1
	NO. of Cylinder	4
	Cylinder Type	L
	RPM	1500
	Bore (mm)	101
	Stroke(mm)	126
	Speed Governor	electronic
	Start system(VDC)	24
	Lub Oil Specification	15W40
	Displacement(Ltrs)	4.04
	Air inspiration	turbo
	Phase	3
Alternator	Brand	KUSING
	Model	S224G64D8
	3 Phase Voltage(1 Phase) Volts	380-415(220-240)
	RPM/Frequency	1500rpm/50hz
	Power Factor(%)	0.8(lagging)
	Voltage Tolerance(+/- %)	1
	Insulation Class	H
Control Panel	Brand	KUSING
	Model	AD6132
Fuel Tank	Capacity(Ltrs)	SUPPORT TO RUN 8-10 HOURS
