Generator set	Type	Open	Open with ATS	Silent	Silent with ATS
	Genset Model	DK35000	DK35000A	DK35000S	DK35000SA
	Prime Power Rating	625KVA/500KW
	Standby Power Rating	687.5KVA/550KW
	Size(mm)	3450*1500*2100		5000*1800*2550
	Weight(KG)	4500		5200
	Internal protection	IP22
	Rate current(A)	902
	Specific Fuel Consumption(g/kW·h)@100% Load	≤212
	Noise at 7 meters away(dB)	N/A		75db
Engine	Model	Deutz BF8M1015CP-LA G5
	NO. of Cylinder	8
	Cylinder Type	L
	RPM	1500
	Bore (mm)	132
	Stroke(mm)	145
	Speed Governor	electronic
	Start system(VDC)	24
	Lub Oil Specification	15W40
	Displacement(Ltrs)	15.9
	Air inspiration	turbo
	Phase	3
Alternator	Brand	KUSING
	Model	S354G500D6
	3 Phase Voltage(1 Phase) Volts	380-415(220-240)
	RPM/Frequency	1500rpm/50hz
	Power Factor(%)	0.8(lagging)
	Voltage Tolerance(+/- %)	1
	Insulation Class	H
Control Panel	Brand	KUSING
	Model	AD6132
Fuel Tank	Capacity(Ltrs)	SUPPORT TO RUN 8-10 HOURS
