TECHANICAL DATA
Generator set	Type	Open	Open with ATS	Silent	Silent with ATS
	Genset Model	CK34000	CK34000A	CK34000S	CK34000SA
	Prime Power Rating	500KVA/400KW
	Standby Power Rating	550KVA/440KW
	Size(mm)	3320*1280*1950		4800*1700*2300
	Weight(KG)	3680		4480
	Internal protection	IP22
	Rate current(A)	722
	Specific Fuel Consumption(L/H)@100% Load	71.4
	Noise at 7 meters away(dB)	N/A		75db
Engine	Model	CUMMINS QSZ13-G3
	NO. of Cylinder	6
	Cylinder Type	L
	RPM	1500
	Bore (mm)	130
	Stroke(mm)	163
	Speed Governor	electronic
	Start system(VDC)	24
	Lub Oil Specification	15W40
	Displacement(Ltrs)	13
	Lub Oil Sump Capacity(Ltrs)	45.42
	Coolant Capacity(Ltrs)	23.1 (only engine)
	Air inspiration	turbo
	Phase	3
Alternator	Brand	KUSING
	Model	S354G400D2
	3 Phase Voltage(1 Phase) Volts	380-415(220-240)
	RPM/Frequency	1500rpm/50hz
	Power Factor(%)	0.8(lagging)
	Voltage Tolerance(+/- %)	1
	Insulation Class	H
Control Panel	Brand	KUSING
	Model	AD6132
Fuel Tank	Capacity(Ltrs)	SUPPORT 8 TO 10 HOURS RUNNING TIME
