Generator set	Type	Open	Open with ATS	Super Silent	Super Silent with ATS
	Genset Model	DK32000	DK32000A	DK32000SS	DK32000SSA
	Prime Power Rating	250KVA/200KW
	Standby Power Rating	275KVA/220KW
	Size(mm)	2480*950*1630		3800*1300*1900
	Weight(KG)	2150		3380
	Internal protection	IP22
	Rate current(A)	361
	Specific Fuel Consumption(g/kW·h)@100% Load	≤195
	Noise at 7 meters away(dB)	N/A		75dB
Engine	Model	TCD8.0(TCD2013-4L)
	NO. of Cylinder	6
	Cylinder Type	L
	RPM	1500
	Bore (mm)	110
	Stroke(mm)	136
	Speed Governor	electronic
	Start system(VDC)	24
	Lub Oil Specification	15W40
	Displacement(Ltrs)	7.8
	Air inspiration	turbo
	Phase	3
Alternator	Brand	KUSING
	Model	S274G200E
	3 Phase Voltage(1 Phase) Volts	380-415(220-240)
	RPM/Frequency	1500rpm/50hz
	Power Factor(%)	0.8(lagging)
	Voltage Tolerance(+/- %)	1
	Insulation Class	H
Control Panel	Brand	KUSING
	Model	AD6132
Fuel Tank	Capacity(Ltrs)	SUPPORT TO RUN 8 TO 10 HOURS
