Generator set	Type	Open	Open with ATS	Silent	Silent with ATS
	Genset Model	DK30400	DK30400A	DK30400S	DK30400SA
	Prime Power Rating	50KVA/40KW
	Standby Power Rating	55KVA/44KW
	Size(mm)	1800*800*1200		2250*980*1250
	Weight(KG)	840		1113
	Internal protection	IP22
	Rate current(A)	72
	Specific Fuel Consumption(g/kW·h)@100% Load	238
	Noise at 7 meters away(dB)	N/A		75db
Engine	Model	Deutz BFM3T
	NO. of Cylinder	4
	Cylinder Type	L
	RPM	1500
	Bore (mm)	98
	Stroke(mm)	105
	Speed Governor	electronic
	Start system(VDC)	12
	Lub Oil Specification	15W40
	Displacement(Ltrs)	3.168
	Air inspiration	turbo
	Phase	3
Alternator	Brand	KUSING
	Model	S224G40B3
	3 Phase Voltage(1 Phase) Volts	380-415(220-240)
	RPM/Frequency	1500rpm/50hz
	Power Factor(%)	0.8(lagging)
	Voltage Tolerance(+/- %)	1
	Insulation Class	H
Control Panel	Brand	KUSING
	Model	AD6132
Fuel Tank	Capacity(Ltrs)	SUPPORT TO RUN 8-10 HOURS
