TECHANICAL DATA
Generator set	Type	Open	Open with ATS	Silent	Silent with ATS
	Genset Model	PGK30240	PGK30240A	PGK30240S	PGK30240SA
	Prime Power Rating	30KVA/24KW
	Standby Power Rating	33KVA/26.4KW
	Size(mm)	1600*750*1135		2250*950*1250
	Weight(KG)	741		975
	Internal protection	IP22
	Rate current(A)	43
	Specific Fuel Consumption(L/H)@100% Load	7.1
	Noise at 7 meters away(dB)	N/A		75db
Engine	Model	Perkins 1103A-33G
	NO. of Cylinder	3
	Cylinder Type	L
	RPM	1500
	Bore (mm)	105
	Stroke(mm)	127
	Speed Governor	electronic
	Start system(VDC)	24
	Lub Oil Specification	15W40
	Displacement(Ltrs)	3.3
	Lub Oil Sump Capacity(Ltrs)	8.3
	Coolant Capacity(Ltrs)	10.2
	Air inspiration	Natural
	Phase	3
Alternator	Brand	KUSING
	Model	S184G25D10
	3 Phase Voltage(1 Phase) Volts	380-415(220-240)
	RPM/Frequency	1500rpm/50hz
	Power Factor(%)	0.8(lagging)
	Voltage Tolerance(+/- %)	1
	Insulation Class	H
Control Panel	Brand	KUSING
	Model	AD6122
Fuel Tank	Capacity(Ltrs)	Support 8 to 10 hours running time
